Compact LTE Cat-4 Cellular Router
Merlin-3103-T2G-QFR-G-DCi0936
Features
✔ Versatile LTE cellular router
• Zero-touch large scale deployment
• Multi-service support: LTE Cat-4 and Ethernet
• Industrial protocol gateway and conversion
• Compact design
✔ Best-in-class Cybersecurity
• Secure Boot ensures software is authentic and unmodified
• Trusted Platform Module keeps cryptographic keys secure
• Cybersecurity suite: 802.1X, IPSec encryption, stateful firewall
✔ Unrivalled Design and Supply Chain Control
• Designed in-house by our R&D team - hardware, operating system, mechanics
• Manufactured in Ireland - final secure assembly processes completed in-house
• Factory pre-configured with SIMs or eSIMs installed as an option
Summary
The Merlin series of versatile cellular routers provide high speed data network connectivity for demanding industrial and smart grid applications. Coupled with the Zero Touch deployment software Activator, it provides cost-effective, reliable, and consistent onboarding of routers in large-scale projects.
This compact, rugged unit is suited to tight spaces. Its high MTBF and wide temperature range support maximum service life.
To achieve best-in-class cybersecurity, the Merlin series is equipped with a TPM (Trusted Platform Module) chip that keeps cryptographic keys secure. Secure Boot ensures that the unit boots using only software that is signed and trusted by manufacturer. A set of cybersecurity tools is available as standard including VPN and stateful Firewall support for data security and user authentication.
Technical Specifications
Compact LTE Cat-4 Cellular Router
Trusted Platform Module
GPS, GLONASS, BeiDou, Galileo
2 x 10/100/1000 Mbit/s, Ethernet TX, RJ45
2 x Mini SIM card slot
3 x SMA compatible connectors - 4G
